Details
Product Line: Articulated Telescopic
Truck Industries: Utilities
Height to Bottom of Platform: Up to 60.1 ft
Horizontal Reach: 38.9 ft
Stowed Travel Height: 11.11 ft (3.35 m)
Hydraulic Controls: Full Hydraulic
Hydraulic Operating Pressure: 2250 psi
Hydraulic Flow Rate: 7.5 gpm
Hydraulic Filtration: 10 micron return | 100 mesh suction
Hydraulic System Type: Open Center
Hydraulic Power Source: PTO Pump
Lower Boom Articulation: 0° to +92°
Inner/Outer Boom Articulation: -25° to +85°
Inner Boom Extension: Up to 141 in
Lower Boom Insulation Gap: 24 in
Lower Boom Lift Eye Capacity: 1000 lbs
Boom Rotation: Continuous
Jib & Winch Capacity: Up to 1000 lbs
