Product Overview
Working Height
17.1 m
Platform Height
15.1 m
Max Outreach
3500 m
Max Capacity
230 kg
Lift Rotation
420°
Insulated or Non-insulated
Yes
Material Handling Option
No
Specifications
Base Vehicle
Mercedes-Benz Sprinter
Unique ID
V655F
Model
VDT-170-F
Base Lift
VDT-170-F
Platform Vehicle Type
Van mounted dual telescopic platform
Wheelbase
3665 cm
Total Length
7465 cm
Bucket
2 man Euro Fiberglass
Flyboom Articulation
200°
Slope Degrees
5/10°
Control system
FPC (Electrohydraulic)
Power source
PTO
Outriggers
Radial
GVWR
5000 kg
Leftover payload
465
