CTA-104-I-PA210001
UTILITY EXPO

Articulated Telescopic, CTA, High Access
INDUSTRIES SERVED
Electric Power Transmission, Electric Utilities
TYPE
Articulated Telescopic, CTA, High Access
HEIGHT RANGE
100ft & Above
MODEL SERIES
CTA (CONDOR)
(254) 717-1747

Product Overview

Location
TEXAS
Year of Chassis
2020
Manufacturer
INTERNATIONAL HV507
Mileage
mi
Working Height
104 ft
Side Reach
50.6 ft
Platform Capacity
2200 lbs

Feature

Location
TEXAS
Front Axle / Tandem Weight
lbs
Rear Tandem / Tridem Weight
lbs
Total Gross Weight
lbs
Fed Dot Limit
59500
Payload Available
lbs
Travel Height
13.5 ft
Travel Length
39.92 ft
Outer Wheelbase
24.42 ft
Body Width
102 in
Chassis Length Bumper-Bumper
40 ft

Chassis

Manufacturer
INTERNATIONAL HV507
Model
CTA104 I
Year
2020
Vin
3HAEHTAT1ML471524
Milage
Engine Hours
Drive Configuration
6X6
#1 Axle
MECHANICAL FRONT DRIVE
#1 Suspension
20K LEAF SPRING
#1 Tire / Wheel
425/65R22.5 /ALUMINUM
#2 Axle
23K SINGLE REDUCTION
#2 Suspension
46K WALKING BEAM
#2 Tire / Wheel
11R22.5 /ALUMINUM
#3 Axle
23K SINGLE REDUCTION
#3 Suspension
46K WALKING BEAM
#3 Tire / Wheel
11R22.5 /ALUMINUM
#4 Axle
N/A
#4 Suspension
N/A
#4 Tire / Wheel
N/A
#5 Axle
N/A
#5 Suspension
N/A
#5 Tire / Wheel
N/A
#6 Axle
N/A
#6 Suspension
N/A
#6 Tire / Wheel
N/A
Gvwr
66K lbs
Engine
CUMMINS L9/370 HP
Transmission
ALLISON RDS3000
Fuel Capacity
70 gal
Def Capacity
9.5 gal
Back Up Alarm
YES
Rear Recover Hooks
YES

Aerial

Model
CTA104 I
Year Of Mfg
2021
Wind Rating
25
Working Height
104 ft
Platform Height
99 ft
Platform Capacity
2200 lbs
Material Handling
YES
Mat. Hdl. Capacity
1500 lbs
Side Reach
50.6 ft
Bucket / Platform
FIBERGLASS
Bucket / Platform Size
60"X40"X42"
Bucket Liner
YES
Bucket / Platform Extended
N/A
Buc / Plat Rotation
180
Buc / Plat Leveling
ELECTRIC/HYDRAULIC
Fly Jib Articulation
N/A
Upper Boom Art
163°
Upper Boom Extension
10.5 ft
Upper Boom Insulated
YES
Ub Ansi Category
A-500KV
Com Across Insulated Boom
WIRELSS DIGITAL DATA LINK
Vacuum Prevention
YES
Up Boom Travel Security
AUTO LATCH
Lower Boom Art
85°
Lower Boom Ext
16.5 ft
Lb Boom Travel Security
AUTO LATCH
Turret Rotation
CONTINUOUS
Outriggers
OUT & DOWN
Max Spread
17.42 ft
Short Jack Spread
12.42 ft
Jack Extension
42.88 in
O / R Controls
ELECTRIC/HYDRAULIC
Auto Chassis Level
NO
Outrigger Control Disable
AUTOMATIC
System Hydraulic Pressure
3000 psi
Primary Hydraulic Power
PTO DRIVEN PUMP
Primary Pump Flow
25 gpm
Secondary Hyd Power
N/A
Backup Electric Pump
YES
Manual Recovery
HAND PUMP
Hp Filter
10 MICRON ABSOLUTE HP COLLAPSE NON BY PASS
Lp Filter
10 MICRON NOMINAL BY PASSING WITH MAGNET
Suction Strainer
100 MESH
Aerial Control
ELECTRIC/HYDRAULIC
Communication
CAN-BUS
On Board Telemetrics
NO
On Board Diagnostics
YES
Graphic Or Text Displays In Both Control Stations
TEXT
Automatic Diplay Messaging
YES
Data Link Across Insulated Boom
WIRELESS DATA LINK
Proportional Aerial Movements
YES
Automatic Envelope Control
YES
Atomatic Bucket / Platform Leveling
YES
Manual Bucket / Platform Leveling
YES
Batteries In Platform
TWO (2) 15 Ahr AGM
Batteries Charge When Stowed
AUTOMATIC
Body
FLAT BED
Body Access
CURBSIDE STAIR WELL
Body Material
ALUMINUM

Options Included

Dot Inspection
YES
Current Annual Inspection
YES
Ansi A Category Certification
A-500KV
Transmission Line Bonding Test
YES
Current Leakage Meter (Von)
YES
Vacuum Valve Testing Kit
YES
Material Handler
YES
Tool Circuit At Bucket / Platform
YES
Underbody Lighting (Led)
NO-OPT
Perimeter Strobes (Led)
NO-OPT
