Product Overview
Working Height
13.3 m
Platform Height
11.3 m
Max Outreach
3300 m
Max Capacity
120 kg
Lift Rotation
420°
Insulated or Non-insulated
Yes
Material Handling Option
No
Specifications
Base Vehicle
Renault Master / Opel Movano
Unique ID
V942L
Model
VTL-135
Base Lift
VTL-37
Platform Vehicle Type
Van mounted telescopic platform
Wheelbase
3682 cm
Total Length
6857 cm
Bucket
1 man Eco Fiberglass
Flyboom Articulation
Fixed flyboom
Slope Degrees
3/5°
Control system
LMC (Electrohydraulic)
Power source
Belt drive
Outriggers
-
GVWR
3500 kg
Leftover payload
425
