Product Overview
Working Height
14.6 m
Platform Height
12.6 m
Max Outreach
3460 m
Max Capacity
230 kg
Lift Rotation
420°
Insulated or Non-insulated
Yes
Material Handling Option
No
Specifications
Base Vehicle
Iveco Daily
Unique ID
V921L
Model
VTL-145-F
Base Lift
VTL-41-F
Platform Vehicle Type
Van mounted telescopic platform
Wheelbase
3520 cm
Total Length
7320 cm
Bucket
2 man Eco Fiberglass
Flyboom Articulation
140°
Slope Degrees
5/10°
Control system
LMC (Electrohydraulic)
Power source
PTO
Outriggers
A-frame
GVWR
5200 kg
Leftover payload
1455
